Overhead Stirrer

Product Specification

Digital Overhead Stirrer Ultra-high torque up to 10 – 550 rpm 350,000 mPas/800 Ncm:

• Torque: 800 Ncm
• Humidity range: 80% RH
• Capacity: Max. 100 l (H2O)
• Power consumption: 250 W
• Material: Die-cast aluminum
• Controller: Digital PID control
• Viscosity (mPas): 350,000 mPas
• Execution: Extremely high torque
• Speed: 10 – 550 rpm, 11:1/60:1 gear ratio
• Engine power: Input: 200W, Output: 180W
• Temperature range: Ambient temperature 0 – 40°C
• Suitable / Suitable for: Specialized in ultra-high viscosity materials
• Stirrer diameter: Clamping force 6 – 10 mm, flexible couplings (6 – 16 mm)

Product Details:

An Overhead Stirrer is a laboratory device used for mixing, stirring, and homogenizing liquid samples in a container, usually with higher viscosity or larger volumes than what a magnetic stirrer can handle. Overhead stirrer HT-DX pro, Ultra-high torque, 10 – 550 rpm, 350,000 mPas/800 Ncm, digital.

Major Application:

□ Food industry – emulsions, sauces.

□ Chemical synthesis – mixing reactants.

□ Paints and coatings – dispersing pigments.

□ Pharmaceuticals – suspending active ingredients.

□ Water treatment – mixing chemicals in large beakers.

Key Features:

√ Speed 10 – 550 rpm.

√ Maximum 100 liters.

√ Low maintenance costs.

√ Large, digital LCD display.

√ Maximum viscosity 350,000 mPas / 800 Ncm.

√ CE certificate and traceability by serial number.

√ Excellent planetary gear design for high torque.

√ Smooth start and change of stirring speed during operation.

√ Brushless high-capacity DC motor: highly efficient stirring performance and precise speed control.

Stirring Tools:

Paddle blade – for suspensions.

Propeller blade – general mixing.

Turbine blade – for strong mixing.

Anchor blade – for viscous materials.

“If you need more information regarding different model, different applications, or working capacity, feel free to contact with our technical team.”
